Save on NAT by switching to IPv6 in 4 simple steps

terraform {
  required_version = "1.5.4"

  required_providers {
    aws = {
      source  = "hashicorp/aws"
      version = "5.10"
    }
  }
}

provider "aws" {
  region = "us-west-2"
}

locals {
  cidr_block         = "10.10.0.0/16"
  availability_zones = ["us-west-2a", "us-west-2b", "us-west-2c"]
  public_subnets     = ["10.10.0.0/20", "10.10.16.0/20", "10.10.32.0/20"]
  private_subnets    = ["10.10.128.0/20", "10.10.144.0/20", "10.10.160.0/20"]
}

resource "aws_vpc" "demo" {
  cidr_block           = local.cidr_block
  enable_dns_support   = true
  enable_dns_hostnames = true

  tags = {
    Name = "demo-vpc"
  }
}

resource "aws_subnet" "public_subnets" {
  count = length(local.availability_zones)

  vpc_id            = aws_vpc.demo.id
  availability_zone = element(local.availability_zones, count.index)
  cidr_block        = element(local.public_subnets, count.index)

  tags = {
    Name = "demo-subnet-public${count.index + 1}-${element(local.availability_zones, count.index)}"
  }
}

resource "aws_subnet" "private_subnets" {
  count = length(local.availability_zones)

  vpc_id            = aws_vpc.demo.id
  availability_zone = element(local.availability_zones, count.index)
  cidr_block        = element(local.private_subnets, count.index)

  tags = {
    Name = "demo-subnet-private${count.index + 1}-${element(local.availability_zones, count.index)}"
  }
}

resource "aws_internet_gateway" "demo" {
  vpc_id = aws_vpc.demo.id

  tags = {
    Name = "demo-igw"
  }
}

resource "aws_eip" "demo" {
  count = length(local.availability_zones)

  tags = {
    Name = "demo-nat-eip${count.index + 1}-${element(local.availability_zones, count.index)}"
  }
}

resource "aws_nat_gateway" "demo" {
  count = length(local.availability_zones)

  subnet_id     = element(aws_subnet.public_subnets.*.id, count.index)
  allocation_id = element(aws_eip.demo.*.id, count.index)

  depends_on = [aws_internet_gateway.demo]

  tags = {
    Name = "demo-nat-public${count.index + 1}-${element(local.availability_zones, count.index)}"
  }
}

resource "aws_route_table" "public_rtb" {
  vpc_id = aws_vpc.demo.id

  route {
    cidr_block = "0.0.0.0/0"
    gateway_id = aws_internet_gateway.demo.id
  }

  tags = {
    Name = "demo-rtb-public"
  }
}

resource "aws_route_table" "private_rtb" {
  count = length(local.availability_zones)

  vpc_id = aws_vpc.demo.id

  route {
    cidr_block     = "0.0.0.0/0"
    nat_gateway_id = element(aws_nat_gateway.demo.*.id, count.index)
  }

  tags = {
    Name = "demo-rtb-private${count.index + 1}-${element(local.availability_zones, count.index)}"
  }
}

resource "aws_route_table_association" "public_rtba" {
  count = length(local.availability_zones)

  subnet_id      = element(aws_subnet.public_subnets.*.id, count.index)
  route_table_id = aws_route_table.public_rtb.id
}

resource "aws_route_table_association" "private_rtba" {
  count = length(local.availability_zones)

  subnet_id      = element(aws_subnet.private_subnets.*.id, count.index)
  route_table_id = element(aws_route_table.private_rtb.*.id, count.index)
}

resource "aws_security_group" "demo_lb" {
  name        = "demo-lb"
  description = "Allow external connections"
  vpc_id      = aws_vpc.demo.id
}

resource "aws_vpc_security_group_ingress_rule" "demo_lb_ingress" {
  security_group_id = aws_security_group.demo_lb.id

  description = "Allow public traffic on port 80"
  from_port   = 80
  to_port     = 80
  ip_protocol = "tcp"
  cidr_ipv4   = "0.0.0.0/0"
}

resource "aws_vpc_security_group_egress_rule" "demo_lb_egress" {
  security_group_id = aws_security_group.demo_lb.id

  description = "Allow access all resources"
  ip_protocol = "-1"
  cidr_ipv4   = "0.0.0.0/0"
}

resource "aws_security_group" "demo_nginx" {
  name        = "demo-nginx"
  description = "Allow accessing other VPC resources and Internet"
  vpc_id      = aws_vpc.demo.id
}

resource "aws_vpc_security_group_ingress_rule" "demo_nginx_ingress" {
  security_group_id = aws_security_group.demo_nginx.id

  description                  = "Allow traffic on port 80 from the LB"
  from_port                    = 80
  to_port                      = 80
  ip_protocol                  = "tcp"
  referenced_security_group_id = aws_security_group.demo_lb.id
}

resource "aws_vpc_security_group_egress_rule" "demo_nginx_egress" {
  security_group_id = aws_security_group.demo_nginx.id

  description = "Allow access all resources"
  ip_protocol = "-1"
  cidr_ipv4   = "0.0.0.0/0"
}

locals {
  ec2_public_key = "ssh-ed25519 AAAAC3NzaC1lZDI1NTE5AAAAIGLOy2T25dmVF9MNjgWSpHSUxAjVz3KUdOcTGy/AJG6D semyon@pisarev.us"
}

data "aws_iam_policy_document" "ec2_assume_role_policy" {
  statement {
    actions = ["sts:AssumeRole"]

    principals {
      type        = "Service"
      identifiers = ["ec2.amazonaws.com"]
    }
  }
}

data "aws_ami" "demo_al2" {
  most_recent = true
  owners      = ["amazon"]

  filter {
    name   = "name"
    values = ["amzn2-ami-kernel-5.10-*"]
  }

  filter {
    name   = "architecture"
    values = ["x86_64"]
  }

  filter {
    name   = "root-device-type"
    values = ["ebs"]
  }

  filter {
    name   = "virtualization-type"
    values = ["hvm"]
  }
}

resource "aws_key_pair" "demo_nginx" {
  key_name   = "demo-nginx"
  public_key = local.ec2_public_key
}

resource "aws_iam_role" "demo_nginx" {
  name               = "demo-nginx"
  assume_role_policy = data.aws_iam_policy_document.ec2_assume_role_policy.json
}

resource "aws_iam_role_policy_attachment" "demo_nginx_ssm" {
  role       = aws_iam_role.demo_nginx.name
  policy_arn = "arn:aws:iam::aws:policy/AmazonSSMManagedInstanceCore"
}

resource "aws_iam_instance_profile" "demo_nginx" {
  name = "demo-nginx"
  role = aws_iam_role.demo_nginx.name
}

resource "aws_instance" "demo_nginx" {
  ami                         = data.aws_ami.demo_al2.id
  instance_type               = "t3.micro"
  key_name                    = aws_key_pair.demo_nginx.key_name
  vpc_security_group_ids      = [aws_security_group.demo_nginx.id]
  subnet_id                   = element(aws_subnet.private_subnets.*.id, 0)
  iam_instance_profile        = aws_iam_instance_profile.demo_nginx.name
  user_data_replace_on_change = true

  user_data = <<-EOF
  #!/bin/bash

  amazon-linux-extras install nginx1
  systemctl enable nginx
  echo "IPv4 -> IPv6" > /usr/share/nginx/html/index.html

  systemctl start nginx
  EOF

  tags = {
    Name = "demo-nginx"
  }
}

resource "aws_lb" "demo" {
  name               = "demo"
  internal           = false
  load_balancer_type = "application"
  security_groups    = [aws_security_group.demo_lb.id]
  subnets            = aws_subnet.public_subnets.*.id

  enable_deletion_protection = true
}

resource "aws_lb_target_group" "demo_nginx" {
  vpc_id = aws_vpc.demo.id

  name            = "demo-nginx"
  port            = 80
  protocol        = "HTTP"
  target_type     = "instance"

  health_check {
    matcher = "200"
    path    = "/"
  }
}

resource "aws_lb_listener" "demo_http_80" {
  load_balancer_arn = aws_lb.demo.arn
  port              = "80"
  protocol          = "HTTP"

  default_action {
    type             = "forward"
    target_group_arn = aws_lb_target_group.demo_nginx.arn
  }
}

resource "aws_lb_target_group_attachment" "demo_nginx" {
  target_group_arn = aws_lb_target_group.demo_nginx.arn
  target_id        = aws_instance.demo_nginx.id
  port             = 80
}

output "demo_lb_dns_name" {
  value = aws_lb.demo.dns_name
}
